Application:
It has microprocessor control, DC
brush-less motor. The SERO rotor is used for erythrocyte washing. The HLA rotor
is for lymphocyte washing.
Features:
- Microcomputer control, DC Brush-less motor,
Silent, constant , stable and high speed accuracy.
- Touch button, parameters can be set
according to demands during operation and stored automatically.
- Digital display, which can switch the
reading between rpm/RCF in real time.
- ABS Outlook injection molding at one time,
with simple appearance, light volume and low noise.
- Lid safety device, with Lid, over-speed
protection system, automatic fault alarm function, safe and reliable. Safety-Lock
lid, which ensures a safe, tight closure on the centrifuge chamber during
operation. Electronic lock and emergency lid release are available.
Specification:
|
Model
|
LC-3
|
|
Rotor type
|
HLA Rotor
|
SERO Rotor
|
|
Max. Speed (RPM)
|
3000 r/min
|
|
Max. RCF
|
2000xg
|
1000xg
|
|
Time Range
|
Programmed
timekeeping
|
|
Speed Accuracy
|
±30r/min
|
|
Noise
|
≤60dB(A)
|
|
Motor
|
Brushless
DC motor
|
|
Voltage Supply
|
AC220V
50Hz 5A
|
|
Dimension (mm)
|
400×310×265mm(L×W×H)
|
|
Weight (kg)
|
15kg
|
Rotor parameters:
|
Name of Rotor
|
Key
|
RCF (xg)
|
Centrifugal time
|
Use
|
|
HLA
Rotor For lymphocyte washing
|
1
|
2000
|
180s
|
Lymphocytes
separation incubated cell separation
|
|
2
|
1000
|
3s
|
Hecatomb
last exenterate (thrombin disposal)
|
|
3
|
1000
|
60s
|
lymphocyte
washing
|
|
SERO
Rotor for Erythrocyte washing
|
1
|
500
|
60s
|
Blood
grouping Observation of hem agglutination reaction.
|
|
2
|
1000
|
15s
|
Cross
matching the testing of antis staphylolytic
|
|
3
|
1000
|
60s
|
Hepatocyte
washing the extraction of serum and plasma.
|
